JBL AM5215/95-WH 2-Way Loudspeaker System with 1 x 15 Inch Low Frequency Driver White
$2,560.00
JBL AM5215/95-WH 2-Way Loudspeaker System with 1 x 15 Inch Low Frequency Driver White. Gear by The Penn Group.
This product drop ships directly from the manufacturer. Products generally ship within 3-10 business days.
Description
The JBL AM5215/95-WH is a medium power, lightweight, 2-way, full-range loudspeaker system comprised of the JBL Differential Drive® dual voice coil and dual magnetic gap 265H-1 380 mm (15 in) low frequency driver and 2408H-1 high frequency 38 mm (1.5 in) exit, 38 mm (1.5 in) voice-coil compression driver. The large format PT™ Progressive Transition waveguide provides excellent coverage in a variety of patterns. The waveguide is rotatable so the loudspeaker system can be used in either the vertical or horizontal orientation. High-slope passive networks minimize band overlap. Well-controlled off-axis response enhances array ability.
Applications
Performing Arts Facilities
Theatrical Sound Design
Auditoriums
Worship Facilities
Live Clubs
Dance Clubs
Sports Facilities
Themed Entertainment Venues
Features:
- 265H-1 Differential Drive® Low-Frequency Driver
- 2408H-1 High-Frequency Compression Driver
- Large PT™ Progressive Transition waveguide for excellent pattern control and low distortion
- Rotatable waveguide for vertical or horizontal orientation
- Bi-Amp/Passive Switchable
- Available in Black, White and WRC/WRX weather resistant finishes
Specifications:
- Frequency Range: (-10 dB) 35 Hz – 20 kHz
- Frequency Response: (±3 dB) 41 Hz – 18 kHz
- Coverage Pattern:
/64: 60° x 40°
/66: 60° x 60°
/95: 90° x 50°
/26: 120° x 60° - Directivity Factor (Q): 14.5
- Directivity Index (DI): 11.6 dB
- Crossover Modes: Bi-amp/Passive switchable
- Passive Crossover Frequency: 2 kHz
- Transducer Power Rating (AES):
LF: 500 W (2000 W peak), 2 hrs
350 W (1400 W peak), 100 hrs
HF: 40 W (160 W peak), 2 hrs - Long-Term System Power Rating: (IEC) Passive mode: 350 W (1400 W peak), 100 hrs
- Maximum SPL – Bi-amp mode:
LF: 125 dB-SPL cont avg
HF: 131 dB-SPL cont avg. - System Sensitivity (1W @ 1m): Passive mode: 98 dB SPL
- Low Frequency Driver: 1 x JBL 265H-1 380 mm (15 in) driver with 50.8 mm (2 in) dual voice coil
- Nominal Impedance: 8 ohms
- Sensitivity (1W @ 1m, within operational band): 99 dB SPL
- High Frequency Driver: JBL 2408H-1, 38 mm (1.5 in) exit compression driver, 38 mm (1.5 in) voice coil
- Nominal Impedance: 8 ohms
- Sensitivity (1W @ 1m): 115 dB SPL
- Waveguide: PT-H66HF-1
- Enclosure: Trapezoidal with 15 degree side angles, 16 mm (5/8 in) exterior grade 11-ply birch plywood
- Suspension Attachment: 15 points (4 top, 4 bottom, 2 each side, 3 rear), M10 threaded hardware
- Finish: Black DuraFlex™ finish. White available upon request
- Grille: Powder coated 14 gauge perforated steel, with acoustically transparent black foam backing
- Input Connector: NL4 Neutrik Speakon® and CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or max width 9 mm (.375 in) spade lugs. Speakon in parallel with barrier strip for loop-through.
- Environmental Specifications: Mil-Std 810; IP-x3 per IEC529
- Dimensions (HxWxD)(vertical cabinet orientation): 30.8 x 16.6 x 19.85″ (783 x 422 x 504 mm)
- Net Weight: 25.0 kg (55 lb)
- Optional Accessories: M10 x 35 mm forged shoulder eyebolts with washers U-Bracket MTU-1
Additional information
| Weight | 55.0 lbs |
|---|
