Shure DH5B/O-LM3 DuraPlex IP57 Omni Headset with LEMO Connector – Black
Original price was: $576.00.$461.00Current price is: $461.00.
Shure DH5B/O-LM3 DuraPlex IP57 Omni Headset with LEMO Connector – Black. Gear by The Penn Group.
This product is currently backordered. You may still place your order, and an update will be provided when the product ships.
Description
With an easy-to-wear headset frame, the Shure DH5B/O-LM3 DuraPlex DH5 features a neutral, full sound quality that lives up to the highest audio standards on any stage or broadcast studio. Also available as a lavalier, DuraPlex has been extensively tested to ensure an IP57 dust-resistant, waterproof rating. The exclusive 1.6 mm Shure Plex cable with DuraPlex won’t kink, offers virtually zero “memory effect,” is fully paintable, and simply lasts longer due to a dual redundant ground, which doubles as a secondary shield.In the theater, on stage, or on television, you can depend on the DuraPlex DH5 headset microphone for consistent professional sound, durability, and longevity.
Features:
- 5 mm omnidirectional subminiature design on a silicone boom pivot system that can be placed on the left or right ear
- IP57 dust-resistant, waterproof rated
- Neutral, full sound quality for film, broadcast, speech, theater, and performance applications
- Advanced 1.6 mm Shure Plex cable: Dual redundant ground in cable serves as secondary shield for unprecedented longevityo – Immune to memory effect and kinks – Fully paintable with typical theater paints, pens, and polishes
- Presence Cap included for tailored frequency response provides additional vocal clarity and presence (3-4 dB boost near 10 kHz)
- Available in two connector types: TA4F (mTQG) and LEMO
Specifications:
- Microphone Capsule: MEMS
- Polar Pattern: Omnidirectional
- Frequency Response: 20 Hz to 20 kHz
- Sensitivity: -42.5 dBV (7.5 mVRMS) @ 1 kHz
- Self-Noise: 31 dB SPL-A A-weighted, Equivalent Acoustical
- Signal-to-Noise Ratio: 63.0 dB
- Maximum SPL1: 32.0 dB SPL 1 kHz @ 1% THD, typical
- Dynamic Range: 101.0 dB Typical
- Microphone Current Draw: 220 µA, maximum
- Bias Voltage Recommended Operating Voltage: 5 VDC
- Housing: Molded ABS
- Polarity:
MTQG: Positive Pressure on diaphragm produces positive voltage on Pin 3 with respect to Pin 1
LEMO: Positive pressure on dia-phragm produces positive voltage on Pin 3 with respect to Pin 1 - Cable Diameter: 1.6 mm
- Cable Length: 66.0 in (1.67 m)
- Net Weight: 20 g (0.7 oz)
- Capsule Dimensions (L x D): 14.5 mm x 5.2 mm
- Boom Length: 13.6 cm
Item Includes:
- 1x Shure DH5B/O-LM3 DuraPlex IP57 Omni Headset
- 1x Case
- 1x Foam Windscreen
- 1x Snap-fit Windscreen
- 1x Single Tie Clip
Additional information
| Weight | 1.0 lbs |
|---|
